Features
High Stability
Low Amplitude and Phase Noise
All-PM Solution
Single Mode-Lock State
figure 9® Technology, Laser Output in Less than 60 Seconds
Repetition Rate 30-100 MHz
Optically Isolated Output
Easy to Integrate
Applications
Laser micromachining
Amplifier seeding
Ultrafast Spectroscopy
Specifications
| Item | YLMO-Seed |
|---|---|
| Central Wavelength | factory set between 1030 nm and 1064 nm, ± 1 nm |
| Average Power | > 200 mW (@50 MHz) |
| Pulse Energy | > 4 nJ |
| Bandwidth | > 15 nm (narrower bandwidth on request) |
| Pulse Width (FWHM) | chirped, supporting < 150 fs |
| Repetition Rate | factory set between 30 MHz and 100 MHz, ± 1 MHz |
| Output Port | SC/APC fiber mating sleeve |
| Polarization | linear, PM fiber (PER: typ >20 dB) |
| Pulse Picking Option (only for 50 MHz or lower) | Realized by integrated fast AOM: Mode 1: Divides repetition rate by factor 3 or higher, pulse energy stays constant. Mode 2: Can be used as fast amplitude modulator. |
Please inquire for your specific combination of average power, center wavelength, spectral width, repetition rate, and also for different lengths for and types of the output fiber patch cord.
